    KH-AUTO BT10 Commercial Cleaning Robot | Compact Powerful 4-in-1 Smart Floor Cleaning for Tight Spaces

    KH-AUTO BT10 is a compact commercial cleaning robot designed for efficient cleaning in narrow spaces and complex environments. With advanced navigation, strong vacuum performance, and 4-in-1 cleaning modes, it delivers smart, thorough, and reliable floor cleaning.

    Description

    KH-AUTO BT10 is a commercial cleaning robot that combines a compact size with powerful cleaning performance. Its compact design allows it to easily move through narrow spaces and complete efficient, thorough cleaning tasks. Equipped with advanced cleaning technology, it can handle cleaning challenges in a variety of complex environments and delivers excellent cleaning performance.

    KH-AUTO BT10 Commercial Cleaning Robot KH-AUTO BT10 Commercial Cleaning Robot KH-AUTO BT10 Commercial Cleaning Robot

    Features

    Compact body

    • Easily passes through narrow spaces as low as 50 cm in height. Smaller size and lighter weight deliver better cleaning results.

    Exceptional edge cleaning

    • The protruding design of the right-side cleaning components enables zero-edge cleaning with the side brush at 0 cm from the edge, the roller brush 3 cm from the wall, and the machine body 5 cm from the wall, leaving no dead corners.

    Excellent vacuum performance

    • The professional suction airflow duct design provides outstanding vacuuming performance, with excellent carpet vacuuming results.

    Flexible manual and automatic switching

    • Autonomous navigation plans the cleaning path without human intervention, and a manual push handle is also available for targeted cleaning in specific areas.

    Wet and dry waste separation

    • The wet/dry separation design ensures better cleaning and floor washing performance by vacuuming first and then washing.

    Professional roller brush

    • Equipped with a larger and more durable roller brush that can withstand greater downward pressure, delivering better cleaning performance while reducing consumable replacement frequency.

    Four-in-one cleaning

    • Sweeping, washing, vacuuming, and dust mopping in multiple cleaning modes.

    Digital management

    • Four-end synchronized digital management enables remote device control, task creation, and real-time viewing of machine status and data.
    TECHNICAL DATA
    Basic Parameters
    Overall dimensions (L × W × H) 520 mm × 420 mm × 490 mm Manual operation Supported
    Weight (without water) 26 kg Cleaning modes Sweeping / Vacuuming / Washing / Dust mopping
    Performance Parameters
    Washing width 350 mm Cleaning speed 0.6 m/s
    Suction squeegee width 400 mm Working efficiency 756 m²/h
    Sweeping width 430 mm Body edge distance 5 cm
    Climbing ability 10% Noise level < 65 dB
    Roller brush downward pressure 39.6 g/cm²



    Roller brush speed 0–700 rpm
    Operating temperature 0°C to 40°C Water tank capacity Clean/Dirty water tank: 10 L /10 L
    Electrical System
    Battery voltage 25.6 V Full-charge runtime 2.5–3 h
    Battery capacity 20 Ah Charging method Charging dock / workstation
    Intelligent System
    Navigation solution Vision + LiDAR Driving recorder Standard






    Sensor system



    Solid-state LiDAR / IMU / electronic anti-collision strip / 2D LiDAR / liquid level sensor / odometer / 3D ToF / panoramic monocular camera



    Remote upgrade Standard
    Stair control Optional
    Handle Optional
